Hammond Manufacturing Type 12 Mild Steel Modular Freestanding Enclosure
October 14, 2018
The HME type 12 Mild Steel Modular Greestanding Enclosure provides users with a rugged housing for industrial control and operator interface in industrial. The modular design permits joining of units together for large scale and mixed use applications. environments and the frames 25mm hole pattern provides extensive component and accessory mounting flexibility. Hammond offer the HME series in a broad range of industry standard sizes.
- Removable solid top panel
- Lifting eyebolts (4)
- Removable bottom panel w/gland plates
- Solid front door with door frame
- Removable rear cover panel
- Inner mounting panel
- Formed 14 gauge steel.
- Fully welded frame with 25mm hole pattern for superior mounting flexibility.
- Foam gasket on all openings provides a dust-tight seal.
- Reinforced eyebolts are provided for easy enclosure lifting.
- Frames can be joined together with an optional joining kit.
- Doors can be easily interchanged, removed and/or reversed.
- Door opening 135°.
- Optional formed 14 gauge steel side panels are sold separately (in pairs).
- Bonding and grounding studs are provided for all doors and panels.
- Phosphatized and finished in RAL 7035 light gray powder coating.
- Inner panel is unpainted galvanized 12 gauge steel.
- UL 508A Type 12
- CSA Type 12
- Complies with
- NEMA Type 12
- IEC 60529 IP54
